Rexroth A10VSO71 Axial Piston Pump 280 Bar 78 L/min Hydraulic

A10VSO71DR/31R-VKC92N00 A10VSO71DR/31R-VKC92N00 A10VSO71DR/31R-VPA12N00
A10VSO71DFR/31L-PKC92K02 A10VSO71DFR/31L-PKC92K05 German made Rexroth axial piston pump A10VSO71 series

FAQ:

1. What is the A10VSO71 pump?

The A10VSO71 is an axial piston variable displacement pump manufactured by Bosch Rexroth. It operates via a swashplate design, allowing adjustable flow rates by changing the swashplate angle. This pump is widely used in high-pressure hydraulic systems for industrial machinery, construction equipment, and marine applications due to its efficiency, compact structure, and pressure adaptability.

2. What are the key technical specifications?

• Displacement (Vg max): 71 cm³/rev

• Nominal Pressure (p nom): 280 bar

• Maximum Pressure (p max): 350 bar

• Speed Range: Up to 2,200 rpm (at Vg max)

• Flow Rate (at nominal speed): 156 L/min

• Weight: ~33 kg (standard model)

• Control Options: Pressure cutoff (DR type), load sensing, or proportional control variants.

3. How does the "pressure cutoff" function work?

The A10VSO71DR variant features a pressure cutoff (DR control) mechanism. When system pressure reaches the preset cutoff value, the pump reduces its displacement to maintain constant pressure, minimizing energy consumption. Contrary to some misconceptions, the swashplate does not always return to the minimum angle; it adjusts dynamically based on flow demand while sustaining pressure.

4. What are common applications?

This pump is ideal for:

• Hydraulic presses and injection molding machines.

• Construction machinery (e.g., excavators, cranes).

• Marine and offshore systems.

• Industrial hydraulic power units.

5. How to troubleshoot performance issues?

• Low Flow/Output: Check for clogged filters, worn seals, or incorrect control settings.

• Overheating: Verify fluid viscosity, cooling system, or excessive pressure settings.

• Noise/Vibration: Inspect for cavitation, air ingress, or misalignment.

Rexroth A10VSO71 hydraulic pump

axial piston pump 78 L/min

280 bar hydraulic gear pump
